ANDROID BUS TICKETING MACHINE

# Technical Specifications **Processor** - Quad-core A53 2.0GHz - Octa-core A53 2.0GHz (Optional) **Operating System** - Android 13 **Memory** - RAM: 2GB, ROM: 16GB - RAM: 3GB, ROM: 32GB (Optional) - Micro SD / TF Card: Supports up to 128GB **Display** - 5.5-inch Display - Resolution: 720 × 1440 **Buttons** - Power Button - Volume + / − Buttons **Audio** - Speaker (1W) - Buzzer - Microphone: Optional **Battery** - Removable Li-polymer Battery - 3.85V / 5000mAh **Adaptor** - 5V / 2A **Camera** - Front Camera: Not Available (2MP Optional) - Rear Camera: 5MP AF (16MP AF Optional) **Scanning** - Camera Decoding - Supports Barcode and Payment QR Code - Optional Scan Engine **Interface** - 1 × Type-C USB OTG - Pogo Pin (5-pin) **Positioning** - GPS, A-GPS - BeiDou, GLONASS, Galileo **Payment** - Magnetic Stripe Card - IC Card - Contactless Card **Environmental Specifications** - Operating Temperature: 0°C to 50°C - Storage Temperature: −20°C to 70°C - Humidity: 5% RH to 95% RH (Non-condensing) **Dimensions & Weight** - Dimensions (L × W × H): 213.6 × 79 × 48.8 mm - Thickness: 18.5 mm at the thinnest point - Weight: 363 g **Printing Specifications** - Media Roll Size: 40 mm - Media Width: 58 mm Printing Paper - Resolution: 203 dpi (8 dots/mm) - Print Speed: 60–80 mm/s - Supports 1D / 2D Barcode Printing
